Markets We Serve
We produce complex multi-layer circuits including heaters, thermistors, and sensors on ceramic substrates that enables innovators to design products for high reliability operating in harsh environments. We are pursuing our AS9100 certification.
Our thick film circuits are printed on Fused Silica and Ferrite, enabling innovators to design their products utilizing unique substrates for optoelectronic or RF needs. Wearable and implantable devices benefit from circuit miniaturization and reliability.
The cost effectiveness and reliability of our products are a perfect solution for the Defense industry. Our thick film solution are highly reliable, enables miniaturization, and highly robust in substrates and circuit designs to creating the perfect package for our soldiers. We are ITAR Registered.
The reliability and ability to operate in harsh environments enables scientists design circuits that operate in temperatures ranging from -100C to 800C.
Our ability to produce complex fine line conductors down to 1 micron on multi-layers enables and print them on a variety of substrates gives chip designers the ultimate flexibility.
What is Thick Film?
Thick-film circuits are produced primarily by the screen-printing process using a stainless steel mesh to produce electronic circuits with fine lines for high density and miniaturization applications. Screen printing was was used by the Greeks and Romans to produce works of art where details are critical.
CMS Circuits is pioneering the printing technique to build multi-layered and highly complex microelectronics utilizing standard and exotic pastes (ink). Our techniques produces highly reliable products that operates in harsh environments.
